Inside TPU and GPU Clusters: The Anatomy of Collective Communication

Two very different machines, one shared problem: getting every accelerator to agree on a tensor as fast as physics allows.

Introduction

Every distributed training run you have ever launched spends a large fraction of its wall clock inside collective communication — the handful of primitives that move and combine tensors across accelerators. Data parallelism needs an All-Reduce over gradients. Tensor parallelism and FSDP need All-Gather and Reduce-Scatter over shards. Mixture-of-experts routing needs All-to-All.

These four operations are where your FLOP/s go to die. And the reason they behave so differently on a TPU pod versus an H100 cluster has almost nothing to do with the algorithms and almost everything to do with the wires.

This post is a ground-up walkthrough of both machines. I want to get to the point where you can look at a sharding strategy, know which collective it implies, and estimate how long that collective will take on the hardware in front of you — without running it.

The one-line mental model: a collective’s cost is total bytes that must cross a cut divided by the bandwidth available across that cut. Topology decides the cut. Algorithm decides the bytes.

Part 1 — Anatomy of a TPU Cluster

TPUs are wired as a torus, not a switch

The single most important structural fact about a TPU pod: there is no switch. Chips are connected directly to their nearest physical neighbours by the ICI (inter-chip interconnect), and the ends of each dimension wrap around. That is a torus.

Which torus depends on the generation:

A pod (or superpod) is the largest ICI-connected island. A v4 pod is a $16 \times 16 \times 16$ grid — 4096 chips. A v5p pod is $16 \times 20 \times 28$ — 8960 chips. A v5e pod is a $16 \times 16$ 2D torus.

A slice is any sub-block of a pod that you actually get allocated: $2 \times 2$, $2 \times 4$, $8 \times 8$, and so on. The largest possible slice is the pod itself.

Why wraparound links earn their keep

Consider a $16 \times 16$ v5e pod and a message from chip $(15, 15)$ to chip $(0, 15)$.

Without wraparound, that is 15 hops along the first axis. With wraparound, it is one. The routing becomes $(15,15) \rightarrow (0,15) \rightarrow (1,15) \rightarrow (2,15)$ and so on — the torus turns the worst case into the best case.

More precisely: on a ring of $N$ chips the maximum distance drops from $N-1$ to $\lfloor N/2 \rfloor$, and — the part that matters for collectives — the number of links crossing any cut of the ring goes from 1 to 2. We will cash that in shortly.

flowchart LR
  subgraph ring["1D slice of a torus (N = 4), wraparound shown dashed"]
    direction LR
    C0["chip 0"] --- C1["chip 1"]
    C1 --- C2["chip 2"]
    C2 --- C3["chip 3"]
    C3 -.-> C0
  end
  class C0 hot
  class C3 cool

The bandwidth hierarchy: ICI, PCIe, DCN

A TPU chip can reach data over three very different paths, and knowing which one a transfer uses explains most surprising slowdowns.

flowchart TD
  HBM["HBM / VMEM<br/>on-chip and on-package"] -->|fastest| ICI["ICI<br/>chip to chip, within a pod"]
  ICI -->|slower| PCIe["PCIe<br/>chip to its host CPU"]
  PCIe -->|slowest| DCN["DCN<br/>host to host, across pods"]
  class HBM hot
  class ICI hot
  class DCN cool

ICI is the fast path: direct, nearest-neighbour, no host involvement. On v5e each link carries 45 GB/s in one direction, with roughly 1 μs of latency per hop.

PCIe connects a chip to its host CPU. On v5e a single host serves a $2 \times 4$ block, so that host owns 8 PCIe links.

DCN (data centre networking) is what you cross when you leave a pod. It is not just “a slower link” — it is a longer path. A DCN transfer looks like:

source HBM → PCIe → source host → DCN → target host → PCIe → target HBM

Every DCN transfer therefore pays PCIe twice plus the network in between. That is why DCN throughput lands below PCIe throughput, and why multi-pod training is structured to keep the frequent collectives inside a pod and only cross DCN for the infrequent ones.

Worked transfer 1 — one matrix, two paths

Take a $2048 \times 2048$ bf16 matrix and move it from chip $(3,3)$ to chip $(0,0)$ on a $4 \times 4$ v5e mesh (no wraparound, so we cannot cheat).

Size first:

The Manhattan distance is $3 + 3 = 6$ hops. But there are two edge-disjoint 6-hop routes: go along $x$ then $y$, or along $y$ then $x$. Split the payload across both and each route carries 4 MiB.

Using a single route instead would cost about 186 μs. The second path buys a genuine 2x — and this is exactly the trick that a bidirectional ring generalises.

Worked transfer 2 — the gather that should never happen

Now a more instructive example, because it fails.

Take a $131072 \times 131072$ bf16 matrix ($128\text{K} \times 128\text{K}$), sharded over a $4 \times 4$ v5e slice. Total size:

Each of the 16 chips owns a $32768 \times 32768$ block — 2 GiB. Say it has been offloaded to host DRAM, and you want to gather all of it onto chip $(0,0)$ and multiply it by a $131072 \times 128$ bf16 matrix.

First, how much compute are we buying?

Arithmetic intensity is where it gets embarrassing. The big matrix is read exactly once, so:

The arithmetic intensity of a skinny matmul is just the narrow dimension. Nice identity, terrible news here.

At v5e’s roughly 200 TFLOP/s of bf16 throughput, 4.4 TFLOP is about 22 ms of compute. Meanwhile, even if the gather ran at full ICI speed with zero contention:

Communication is ~34x the compute. And that is the optimistic bound — it ignores that the data starts in host DRAM (so it crosses PCIe), that any shard living under a different host crosses DCN, and above all that every byte must funnel through one chip’s single ingress port. No topology cleverness fixes a funnel.

The lesson generalises past this contrived example: do not gather to compute. Shard the matmul so each chip multiplies its own block and reduce the small result, and the 34 GB never moves at all. Which is precisely what tensor parallelism is, and precisely why the collective you choose is a property of your sharding, not an afterthought.

Part 2 — A Cost Model for Collective Communication

This is the part I wish someone had handed me first. Every ring-collective cost formula you have seen memorised falls out of a single argument, and once you have it you can re-derive any of them on a whiteboard.

The argument

Suppose an algorithm requires a total of $H$ byte-hops — the sum, over every byte sent, of the number of links that byte traverses. Suppose the fabric offers $C$ bytes/second of aggregate link capacity — the sum of the bandwidths of every directed link.

If the schedule keeps all links busy, then:

That is it. Count byte-hops, count capacity, divide. Every result below is one instance of this.

Notation for the rest of the post:

• $N$ — number of participating chips
• $W$ — unidirectional bandwidth of one link (45 GB/s on v5e ICI)
• $D$ — for All-Gather / Reduce-Scatter, the size of the full (gathered or unreduced) array in bytes; each chip owns $D/N$ after a scatter
• $S$ — for All-to-All, the bytes each chip holds locally before the exchange

Capacity for a 1D ring of $N$ chips: there are $N$ links, each full-duplex, so

All-Gather, derived

Every one of the $N$ shards (size $D/N$) must reach every other chip. On a bidirectional ring, a shard is broadcast both ways, travelling about $N/2$ hops clockwise and $N/2$ counter-clockwise — $N$ link traversals in total. So:

On a unidirectional ring each shard must traverse $N-1$ links, capacity halves, and you get $T \approx D/W$ — exactly 2x worse.

Stare at that boxed result for a second, because it is the single most useful fact in this post:

Ring All-Gather time does not depend on $N$. Gathering 1 GB across 8 chips and across 8000 chips costs the same, to first order.

That is the whole reason ring collectives are the default. The step count grows with $N$ ($N-1$ steps on a unidirectional ring — 3 steps for $N=4$), but each step shrinks proportionally, and the product is constant.

Reduce-Scatter is All-Gather run backwards

Reduce-Scatter uses the same schedule, with one change: when a shard arrives, you add it into the local buffer instead of storing it alongside. The bytes on the wire are identical, so:

This duality is not a coincidence, and it shows up in your autograd graph: the backward pass of an All-Gather is a Reduce-Scatter, and vice versa. If your forward pass all-gathers a sharded weight, your backward pass reduce-scatters its gradient. Same cost, same schedule, opposite direction.

All-Reduce is just the two of them

Reduce-scatter so every chip owns the reduced value for one shard, then all-gather so everybody has all of them. Also $N$-independent. Also the reason “ring all-reduce” became the industry default for data-parallel gradient synchronisation.

All-to-All is the one that scales badly

Here each chip holds $S$ bytes split into $N$ chunks of $S/N$, one per destination. This is a distributed transpose.

On a bidirectional ring with uniform destinations, the distances from one chip to the others sum to roughly $2\sum_{d=1}^{N/2} d \approx N^2/4$. So the byte-hops contributed by one source are $(S/N) \times (N^2/4) = SN/4$, and over all $N$ sources:

This one is linear in $N$. Where All-Gather is topology’s free lunch, All-to-All is the bill.

Note also that All-to-All gains a factor of 4 from bidirectional links (halved distances and doubled capacity), whereas All-Gather only gains 2 (capacity doubles, but a broadcast still has to cover everything). Two collectives, two different payoffs from the same wire.

What this predicts about topology

Three corollaries fall straight out of the capacity term:

Everything here is a consequence of the same division. Topology only ever changes the denominator.

The chain penalty is worth spelling out because it justifies the earlier warning about slice shapes: a cut through the middle of a ring severs two links; the same cut on a chain severs one. Half the capacity, twice the time.

Part 3 — The Four Collectives on a Torus

With the model in hand, the algorithms are almost anticlimactic. Here is what each one actually does.

All-Gather, step by step

Four chips, each starting with one shard, on a unidirectional ring. Each step, every chip forwards the shard it received last step to its neighbour. After $N-1 = 3$ steps everyone holds everything.

Unidirectional ring All-Gather, N = 4. Three steps, each moving one shard per link. Total bytes on the wire per chip: 3 x (D/4) — hence (N−1)/N · D/W ≈ D/W.

The variants, all of which we have already priced:

• Unidirectional 1D ring — $N-1$ steps, $T \approx D/W$.
• Bidirectional 1D ring — split the shards into two halves and send one each way, $T \approx D/(2W)$.
• Chain / path — the fallback when an axis has no wraparound. Roughly 2x the ring.
• Bidirectional 2D ring — use all four ICI links by running the gather over both axes. Another 2x over one axis.

Reduce-Scatter, step by step

Same movement, different arithmetic. Each chip starts with a full copy of a 4-part array and ends owning the fully reduced value for exactly one part.

Reduce-Scatter on a ring, N = 4. Identical byte movement to All-Gather; the only difference is that arriving data is accumulated rather than appended. Same cost: D/(2W) bidirectional.

Because the schedule is shared, everything you know about tuning All-Gather transfers directly. And All-Reduce is literally these two stacked, which is why its cost is $D/W$ and why almost no production system implements All-Reduce as a monolithic algorithm.

All-to-All: a sharded transpose

All-to-All is the odd one out. Nothing is broadcast and nothing is reduced — every chunk has exactly one destination.

All-to-All as a distributed transpose: the chunk grid is transposed across chips. Read the “before” column as rows of a matrix and the “after” column as its columns.

This is the collective that mixture-of-experts routing needs. With top-1 routing and one expert per chip, each token’s hidden state has to travel to whichever chip owns its chosen expert, and the results have to come back.

The ring variants mirror All-Gather’s — bidirectional, unidirectional, and chain — but every one of them carries the $N$ in the numerator. That single factor is why expert parallelism is so much more sensitive to cluster shape than tensor or data parallelism, and why MoE systems work so hard to keep routing local.

Part 4 — Anatomy of a GPU Cluster

Now the other machine. I will use the DGX H100 SuperPOD reference architecture as the concrete example: 1024 GPUs, arranged as a fat tree. I am only looking at the compute fabric here — a real deployment also has a separate storage fabric plus in-band and out-of-band management networks, and none of that carries collectives.

Two networks, stacked

A GPU cluster is not one fabric, it is two, and their bandwidths differ by nearly an order of magnitude.

flowchart TD
  SPINE["InfiniBand spine switches"] --- L1["IB leaf switches (SU 1)"]
  SPINE --- L2["IB leaf switches (SU 2)"]
  L1 --- N1["node: 8x H100<br/>+ NVSwitch"]
  L1 --- N2["node: 8x H100<br/>+ NVSwitch"]
  L2 --- N3["node: 8x H100<br/>+ NVSwitch"]
  L2 --- N4["node: 8x H100<br/>+ NVSwitch"]
  class SPINE cool
  class N1 hot
  class N2 hot
  class N3 hot
  class N4 hot

Inside a node is the NVLink scale-up domain. On DGX H100 that is 8 GPUs behind NVSwitch; on GB200 NVL72 it is 72. Topologically this is the opposite of a torus: every GPU can reach every other in one switch hop, at full bandwidth. 450 GB/s per GPU, per direction.

Between nodes is InfiniBand. Each H100 has its own NIC at 50 GB/s, so a node injects

into the network — 9x less than what the same 8 GPUs enjoy internally. Thirty-two nodes hang off a set of IB leaf switches to form a Scalable Unit (SU) of 256 GPUs; SUs are joined through spine switches. Four SUs gives you the 1024-GPU cluster.

Bisection bandwidth, tier by tier

The cut-and-divide model from Part 2 applies unchanged; we just have to compute the cut at each tier. Split the machine in half and add up the bandwidth crossing the split.

Bisection bandwidth for a 128-node DGX H100 cluster, computed from published per-GPU NVLink (450 GB/s) and per-GPU NIC (50 GB/s) figures. Green row is intra-node NVLink; magenta rows cross InfiniBand.

Two things to take from that table. First, the uneven split is limited by the smaller side — 40 nodes can only inject 16 TB/s no matter how much capacity the other 88 have. Second, a single node’s internal bisection (1.8 TB/s) is 28% of the entire 32-node SU’s bisection. That ratio is the whole design pressure behind scale-up domains, and behind NVL72.

Rings on a switch are a fiction (a useful one)

Here is a distinction that took me a while to internalise.

On a TPU, a “ring” is a physical object: chip $i$ genuinely has a wire to chip $i+1$, and a ring collective walks real cables. On a GPU node, a ring is a logical ordering imposed on an all-to-all switch fabric. NCCL numbers the GPUs, pretends $i$ talks to $i+1$, and NVSwitch routes it.

Which raises the obvious question: if every GPU can already reach every other in one hop, why impose a ring at all?

Because rings pipeline. A ring schedule keeps every link busy with a steady stream of chunks, which is exactly what you want for large messages. But for a switched fabric you can do better on the cost model, because there is no relaying: a chunk goes straight to its destination, and the only constraint is each GPU’s own port.

All-to-All on a switch, ingress-bound:

All-to-All on a bidirectional ring, from Part 2:

For $N = 8$ those are within about 15% of each other — the switch wins, but barely. For $N = 72$ on an NVL72, the ring model gives $9S/W$ against the switch’s $\approx S/W$: a 9x gap. The switch’s advantage is structural, and it widens with the size of the scale-up domain. Which is, more or less, the entire argument for building NVL72.

SHARP: making the switch do the arithmetic

NVSwitch and InfiniBand switches carry reduction hardware — NVIDIA calls the feature SHARP. Instead of GPUs exchanging partial sums and summing them in their own SMs, the switch sums packets in flight.

flowchart LR
  G0["GPU 0<br/>partial"] --> SW["NVSwitch<br/>SHARP reduction unit"]
  G1["GPU 1<br/>partial"] --> SW
  G2["GPU 2<br/>partial"] --> SW
  G3["GPU 3<br/>partial"] --> SW
  SW -->|"reduced result, multicast"| OUT["all GPUs"]
  class SW hot
  class OUT cool

Two wins, and they are different in kind:

Bandwidth. A ring All-Reduce moves each byte twice — once for the reduce-scatter, once for the all-gather. With in-network reduction the theoretical speedup is

which is 1.75x at $N=8$ and approaches 2x as $N$ grows.

Resources. The reduction no longer consumes SM cycles or HBM bandwidth. The NVLink 4 NVSwitch provides roughly 400 GFLOP/s of FP32 reduction throughput — modest as FLOP/s go, but it is throughput you were otherwise stealing from your matmuls.

SHARP also accelerates All-Gather, via hardware multicast. You register a memory region as a multicast target, and then an ordinary CUDA store gets replicated by the fabric to every participant. No special instruction, no explicit sends — the write just lands in several places.

Trees: when $\log N$ beats $N-1$

Rings are not the only option on a switched fabric. Tree algorithms pair GPUs in rounds and double the data each round, finishing in $\log_2 N$ steps instead of $N-1$.

Recursive doubling All-Gather, N = 8: three rounds instead of seven. Reduce-Scatter is the same schedule run in reverse — recursive halving.

Sum the bytes column: $D/8 + D/4 + D/2 = 7D/8 = (N-1)D/N$. Identical to the ring. The ideal-model cost is the same; only the step count differs.

So the choice is not about bytes, it is about which inefficiency you would rather pay:

• Rings pipeline well — fewer, larger, steadier transfers. Better for large messages.
• Trees finish in fewer rounds — less per-step latency accumulated. Better for small messages.

Which is exactly why NCCL does not pick one. It selects ring, tree, or a hybrid at runtime based on message size and detected topology, and this is the single biggest reason a hand-rolled collective usually loses to it.

Hierarchical collectives: the model that matters in production

Cross-node collectives are never flat. NCCL does the intra-node part over NVLink, then one cross-node stage over InfiniBand, then distributes locally again. So the naive model is:

But the intra-node and scale-out stages pipeline, so a better first-order estimate is:

With $BW_{\text{gpu}} = 450$ GB/s and $BW_{\text{node}} = 400$ GB/s on DGX H100, those are close enough that the inter-node term dominates but does not run away — the architecture is reasonably balanced for All-Reduce.

Make it concrete. A 70B-parameter model’s bf16 gradients are about 140 GB. A hierarchical All-Reduce across nodes is reduce-scatter plus all-gather:

That is per optimiser step, and it is why nobody runs a naive synchronous all-reduce at the end of the backward pass. Real frameworks bucket gradients and overlap each bucket’s all-reduce with the backward computation still to come, so most of that 0.7 s hides under compute. With SHARP’s reported ~1.3x you would shave it to roughly 0.54 s of exposed cost in the worst case.

Two closing wrinkles that bite in practice:

All-to-All does not compress. Hierarchical All-Reduce works because the intra-node stage reduces data before it crosses the expensive link — 8 GPUs’ worth of gradients leave the node as one gradient. All-to-All has no such property: every chunk has a specific destination, so nothing can be combined locally. Cross-node All-to-All pays the full byte count over the 400 GB/s link. This is the real reason expert parallelism wants to stay inside a scale-up domain.

Node bandwidth is not fungible. That 400 GB/s figure assumes all 8 NICs are usefully engaged. Clusters are wired with parallel network rails, where each GPU has a preferred path through the fabric. If your rank placement is rail-unaware, traffic collides on some rails and idles others, and you see a fraction of nominal bandwidth for no algorithmic reason. Rail-aware placement is unglamorous and routinely worth double-digit percentages.

Key Takeaways

• One model covers everything. A collective costs byte-hops divided by aggregate link capacity. Topology sets the denominator; the algorithm sets the numerator. Every ring formula is one instance of that division.

• All-Gather, Reduce-Scatter and All-Reduce are $N$-independent. On a bidirectional ring they cost $D/2W$, $D/2W$ and $D/W$ regardless of how many chips participate. This is why ring collectives scale to pods of thousands.

• All-to-All is linear in $N$ — $NS/8W$ on a ring. That single factor is why mixture-of-experts routing is the most cluster-shape-sensitive thing in modern training, and why MoE systems fight to keep routing inside one domain.

• Forward All-Gather implies backward Reduce-Scatter. They are the same schedule with copy swapped for accumulate, at identical cost. Recognising the pair tells you your backward-pass communication for free.

• TPUs and GPUs solve the same problem from opposite ends. A torus gives cheap, uniform nearest-neighbour bandwidth that scales to 8960 chips; a switched NVLink domain gives enormous non-local bandwidth to 8–72 GPUs and then falls off a 9x cliff at the node boundary.

• Hierarchy is the GPU answer, and it only works when data compresses. Reducing inside a node before crossing InfiniBand is what makes cross-node All-Reduce affordable. All-to-All cannot be compressed that way, and pays in full.

• Theory is a bound, not a prediction. In-network reduction promises ~1.75x and is reported to deliver ~1.3x. GPU collectives are reported to still be ramping at multi-gigabyte messages. Use the models to spot factor-of-two problems, then measure.

• Never gather to compute. A 32 GiB gather to feed 4.4 TFLOP of matmul spends ~34x more time moving bytes than doing arithmetic. Shard the computation instead — that is the whole idea behind tensor parallelism.

Related Reading on This Site

• Why We Need Distributed Training and Inference — the motivation layer beneath this post: why a single accelerator stopped being enough.
• Megatron-LM: Tensor, Pipeline and Data Parallelism — where each of these collectives actually gets emitted, and along which mesh axis.
• Inside NVIDIA GPUs: How High-Performance Matmul Kernels Actually Work — the intra-chip counterpart. Same cut-and-divide reasoning, applied to the memory hierarchy instead of the network.
• The XLA Compiler: GPU Kernels, Fusion, cuBLAS and Triton — how a sharding annotation becomes the collectives described here.

Conclusion

The thing that finally made collective communication click for me was realising how little of it is about the algorithms.

All-Gather, Reduce-Scatter, All-Reduce and All-to-All are, at heart, four ways to schedule the same primitive: move bytes across a cut. What changes between a TPU pod and an H100 cluster is not the schedule — it is how many wires cross the cut, and whether the data can be made smaller before it gets there.

Once you hold that, the design decisions stop looking like vendor trivia. A torus is a bet that nearest-neighbour bandwidth scales further than switches do. NVL72 is a bet that the node boundary is the thing worth pushing out. SHARP is a bet that the cheapest byte is the one the switch adds for you. Every one of them is an attempt to change a denominator.

Which leaves a question I do not think is settled. As models push harder on sparsity, the collective that matters most is shifting from All-Reduce — the $N$-independent one, the one both architectures are genuinely good at — toward All-to-All, the one that scales linearly and cannot be compressed by hierarchy.

If the dominant collective is changing, does the right topology change with it?
